| system |
Model |
Q8-4M-8X |
| Image sensor |
2 2m 1/3.2" SC2331 High performance CMOS sensors |
| Operating system |
Embedded LINUX operating system |
| Image coding format |
Smart H.265X |
| APP |
Super Look (Android and IOS support) |
| Video |
Effective video pixel |
2MP |
| Video processing |
H.265AI coding, double code stream,AVI format; Bitstream 0.1M~10Mpbs adjustable; The frame rate is adjustable from 1 to 30 frames per second |
| resolution |
Main code stream: 1920*1080@12fps; Substream: 800*448@12fps |
| Minimum illuminance |
0.01 LUX/pro series |
| lens |
5x zoom |
| perspective |
90 ° |
| |
Video flip |
Flip up and down/flip side to side |
| lighting |
Light control mode |
Starlight full color/intelligent warning/infrared night vision |
| Number of fill lights |
4 infrared +6 white |
| PTZ |
Head control |
Rotation Angle level :355°; Vertical :90° |
| Head flip |
Flip up and down/flip side to side |
| Audio |
Coding standard |
G.711 |
| pickup |
support |
| horn |
support |
| Record management |
Video file size |
≈12G/ day |
| Record Mode |
Manual record, motion detection record, scheduled record, alarm record |
| Video storage |
TF Card/Cloud |
| storage |
support TF card（max 128GB) or cloud storage |
| Remote playback |
Support |
| Image capture |
Support |
| Network |
WIFI |
2.4G WIFI 802.11b/g/n |
| Pairing |
WiFi Smartlink distribution network addition, AP hotspot addition, QR code scanning. Bluetooth fast networking |
| Network Protocol |
Support TCP/IP, ONVIF, RTSP |
| extension |
Reset key |
Support |
| Human tracking |
Support |
| 360degree coordinate positioning |
Support |
| power supply |
Power |
AC110-230V |
| power interfac |
E27 |
| work environment |
Suitable place |
outdoor、Home、shop、School、factory； |
| Installation mode |
Wall mounted、hoisting |
| Working Temperature |
-20℃－＋55℃ |
| Working humidity |
10%－90% |
